- Use the sheet which shrinks deeply (OPS etc.)
- The forming needs to match with the printed sheet.
- Need a machine having both forming and trimming facilities
- Need in-mold cutting machine for space saving.
- Need forming test before purchasing machine
Compact pressure and vacuum forming machine
Product examples)
Food container, automobile
component
- Need to add the value to the surface of base material
3D surface decorative forming machine
Product examples) Electric appliance, automobile appliance
Forming machines' spec list
Forming machine | |||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|
FLC | CLS CLC |
FLB | FLTP | FLT | EFL | FCS | FKS | FKH | FC | ||
Forming method | Vacuum | ○ | ○ | ○ | ○ | ||||||
Vacuum and pressure | ○ | ○ | ○ | ○ | ○ | ○ | |||||
Heating method | Radiant heating | ○ | ○ | ○ | ○ | ○ | ○ | ○* | |||
Contact heating | ○ | ○ | |||||||||
Heater | Asano Quick response heater | ○ | ○ | ○ | ○ | ○ | ○ | ||||
Aluminum casting heater | ○ | ○ | |||||||||
Ceramic heater | ○ | ||||||||||
Forming table | AC servo drive | ○ | ○ | ○ | ○ | ○ | ○ | ○ | |||
Air cylinder drive | ○ | ||||||||||
Hydraulic cylinder drive | ○ | ||||||||||
Trimming method | Steel rule | ||||||||||
Die punching | ○ | ||||||||||
Sheet | Roll sheet | ○ | ○ | ○ | ○ | ||||||
Cut sheet | ○ | ○ | ○ | ○ | ○ | ○ | |||||
Product | Food container | ○ | ○ | ○ | ○ | ||||||
Blister pack, Industrial tray | ○ | ○ | ○ | ○ | ○ | ||||||
Automobile component | ○ | ○ | ○ | ○ | ○ | ○ | ○ | ○ | |||
Electric appliance, building material |
○ | ○ | ○ | ○ | ○ | ○ |
* Upper Heater Only
Forming+cutting machine | Cutting machine | ||||||||
---|---|---|---|---|---|---|---|---|---|
FI | FLCD | FLD | TFH | PLS PLS7 |
PLS20 PLP |
PLAS | PLB | ||
Forming method | Vacuum | ||||||||
Vacuum and pressure | ○ | ○ | ○ | ○ | |||||
Heating method | Radiant heating | ○ | ○ | ○ | |||||
Contact heating | ○ | ||||||||
Heater | Asano Quick response heater | ○ | ○ | ○ | |||||
Aluminum casting heater | ○ | ||||||||
Ceramic heater | |||||||||
Forming table | AC servo drive | ○ | ○ | ○ | ○ | ○ | ○ | ○ | |
Air cylinder drive | ○ | ||||||||
Hydraulic cylinder drive | |||||||||
Trimming method | Steel rule | ○ | ○ | ○ | ○ | ○ | ○ | ○ | |
Die punching | ○ | ||||||||
Sheet | Roll sheet | ○ | ○ | ○ | ○ | ○ | ○ | ○ | |
Cut sheet | ○ | ○ | |||||||
Product | Food container | ○ | ○ | ○ | ○ | ○ | ○ | ||
Blister pack, Industrial tray | ○ | ○ | ○ | ○ | ○ | ||||
Automobile component | ○ | ||||||||
Electric appliance, building material |
○ |
