We have experimental machines for thermoforming. If you want to test about thermoforming, please feel free to contact me.

Forming test
Vacuum forming / Pressure forming / Pressure and Vacuum forming / Hot plate forming / Matched mold forming
Heating test
Experimental machines have Asano's quick response heater.
Mold
We have some kind of mold for testing. And you can bring your mold in our facility.
We also can arrange the mold to meet your requirements.

FKS Compact multifunction pressure and vacuum forming machine

FKS Compact multifunction pressure and vacuum forming machine

Model FKS-0632-20
Max. forming area 600(W) x 600(L)mm
Max. forming depth 150mm
Heater Quick response heater
Forming table Mold clamping force 200kN
AC servo motor drive
Control Fully automatic, PLC control

Process

TFH 3D Surface Decorative Forming Machine

TFH 3D Surface Decorative Forming Machine

Model TFH-0121
Max. forming area 170(W) x 120(L)mm
Max. forming depth 30mm
Heater Hot plate
Forming table driving method Air cylinder
Pressure air Max. 0.9MPa

Process

Request testing

STEP1

Contact Asano

Ask Asano Lab Tel +81-561-20-9251 / Fax +81-561-20-9261

STEP2

Confirm the contents of testing

Material,Parameter, Mold, etc.

STEP3

Submit the quotation

STEP2

Test implementation

Assess the heating and the forming.
