EFL Pressure and Vacuum thermoforming machine Interlocking extruder

FLTP Continuous pressure and vacuum forming machine for cut sheet

A machine forms and trims the sheets which are extruded by extruder. Suits for mud-guard and fender liner.

After trimming scraps are collected, extruded and formed again by extruder.

Compared with injection forming, the mold cost is cheaper and the cycle is faster.




Main forming products Mud-guard, Fender Liner etc, automobile compoments
Materials HDPE
Forming method Vacuum and pressure forming
Forming table driven AC servo motor drive
Model Max. forming area
(W x L, mm)
Max. forming depth
Max. mold clamping force
Trimming force
EFL-960-40 1000 x 2000 height of formed part positive 600, negative 100 400 600
