PLS20 Continuous trimming machine with steel rule die cutting

PLS20 Continuous trimming machine with steel rule die cutting

Steel rule die type's trimming machine. Connected with FLC, CLS etc forming machine, production line gets high speed and stable.

Sheet feeding, forming table, knock-out and counting table are AC servo motor drive. Scrap winder equipment is standard specification.

Process

Process

Specification

Sheet feeding method AC servo motor driven, double roll feed
Trimming table driven Crank type by AC servo motor drive
Model Max. trimming area
(W x L, mm)
Max. product height
(mm)
Max. trimming speed
(spm)
Trimming force
(kN)
PLS20 1050 x 320 150 100 200
